How to Read a Nautical Chart

Last Updated on November 3, 2023 by Boatsetter Team

Raise your hand if you’ve ever driven your car with a good old-fashioned paper map or modern-day navigation device providing help. For boats, nautical charts are the utmost resource for safely navigating from point A to point B, especially when you’re a newbie boater.

They’re equally advantageous when you’re in unfamiliar waters regardless of your experience level. In fact, nautical charts delineate both what’s visible and what’s not visible. Thankfully, for essentially every waterway nationwide, there’s a chart.

If you’ve never read a nautical chart before, though, here’s how to understand all the markings on them:

• Scale
• Depths
• Contour lines
• Aids to navigation
• Symbols & abbreviations
• Distance

Rent, Charter, Share— Only at Boatsetter

Scale

Scale on a nautical chart is the ratio between the inches on the chart and the real-world distances. So, for instance, a scale of 1:20,000 means that 1 inch on the chart is 20,000 inches of actual distance. For better understanding, 1 inch on the chart is a fraction of a nautical mile, 0.4 nautical mile to be exact.

Therefore, 2.5 inches is the equivalent of 1 nautical mile. Additionally, nautical charts are either small-scale charts or large-scale charts. Small-scale charts provide a lot of detail but cover a smaller area. A harbor chart is a good example. Large-scale charts, meanwhile, provide less detail but cover a bigger area. Here, a good example is a coastal chart.

Depths

You’ll see a lot of small numbers on nautical charts. These indicate the water depth at what’s called Mean Lower Low Water (MLLW). This is the average water depth at the smaller (lower) of the two low tides each day.

Depth lets you know how shallow or deep the water is, and therefore whether you have enough clearance beneath your boat to enter the area. Now, just because you see a number on a chart doesn’t necessarily mean you have that many feet of depth.

Nautical charts use different units of measure, with the key at the top right corner. A common unit of measure you’ll see for U.S. waters is “soundings in fathoms and feet.” “Soundings” is another word for depth, while “fathoms” is the equivalent of 6 feet.

A chart with the numeral 02 indicates that particular area is zero fathoms and 2 feet, therefore just two feet deep. But, a chart with the number 55 means 5 fathoms and 5 feet, therefore 35 feet deep.

READ MORE: Can a Pontoon Go Into the Ocean?

Contour lines

These are curving and sometimes circular lines. They paint a picture of what the waterway’s bottom looks like. Typically, contour lines are in fathoms. Depending on the waters you’re cruising and the chart you’re using (large- vs. small-scale), there could be significant changes in depth between contour lines.

Pro tip: The National Oceanic and Atmospheric Administration (NOAA) provides more than 1,000 charts covering 95,000 miles of shoreline and 3.4 million square nautical miles of water, which you can download here.

Aids to navigation

Before heading out for the day, it’s important to understand where buoys, lights, and countless other waterway markers are. When you read a nautical chart, look for special symbols representing each of these.

Chart aids to navigation also include symbols for safe water and the sides of a channel. Overall, it’s in keeping with the idea of informing you about things both visible and invisible.

Symbols & abbreviations

Speaking of visible and invisible, you potentially can come across a reef or rocks when you cruise. You also can encounter wrecks and even lighthouses. Thankfully, NOAA has all sorts of symbols, as well as abbreviations for these, too.

Because there are so many, and they’re not all intuitive, NOAA has a downloadable booklet, Chart No. 1: Symbols, Abbreviations, and Terms, explaining them all.

Distance

Most nautical charts depict distances in nautical miles, with 1 nautical mile being 1.15 statute miles. However, charts for the Great Lakes, some additional inland lakes, and the Intracoastal Waterway depict distances in statute miles.

If you want to figure out how long it will take you to cover a distance, cruising 1 nautical mile in 1 hour means traveling at 1 knot of speed.
